Xplore CV X8

4 Berth
3500kgs / 68.89cwt
£74,999 *

Including first year VED, delivery, registration and PDI of RRP £1,690


Find an approved retailer

Browse your local dealers


Enquire about this model

Get a quote on your chosen model


Introducing the all-new Xplore CV X8 a brand-new campervan designed for Adventurers

Xplore is made for thrill-seekers and adventurers, for action-packed roadtrips full of fun!

Xplore, part of the Erwin Hymer Group, now presents the first of our motorised range: the 4-berth, pop-top Xplore CV X8.

Our new Xplore campervan turns heads, with its glimmering Black metallic finish and dynamic decals. All-terrain tyres, with colour-coded wheelarch flares, mudflaps, front grille and trim give full-throttle impact!

The debut of the all-new Xplore CV X8 at the NEC Motorhome & Caravan Show

Peter Vaughan from MMM & What Motorhome Magazines visited the Xplore stand during the big build up of the NEC Caravan Show to get an access all areas preview of our exciting new concept adventure vehicle.

The model shown in the video is a concept pre-production model. Model shown and detail on the website is subject to change.



Sleeping up to four in space and comfort (two downstairs at the rear and two ‘up top’), our Xplore CV X8 is fully-kitted out with on-board bathroom and kitchen – with fresh, modern interior design, fixtures and fittings throughout

Find Your Xplore CV X8 Dealer

We have Xplore CV X8 Dealers throughout the UK!

Use our dealer locator below to locate your local dealer and start your adventure today!

Detailed Specification

Detailed Specification

The model shown is a concept pre-production model. Model shown and detail on the website is subject to change.

  • Fiat Ducato Series 9
  • DAB Radio with steering mounted controls
  • Remote central locking to cab and habitation door via key fob (can operate the habitational door independently)
  • Immobiliser with unique code
  • Driver and passenger airbags
  • On-board trip computer
  • Cruise Control
  • ABS brakes with emergency braking assistance and high level brake light
  • Power steering with adjustable steering wheel position
  • Door panel storage. Inc, bottle holder & 4 storage areas
  • 12V DIN socket - for 12V power supply from the cab
  • Headlamp height adjustment
  • Electrically heated adjustable wing mirrors with direction indicators
  • USB Socket
  • Daylight running headlights
  • Fully adjustable co-ordinated cab seats with arm rest
  • Seat belt reminder
  • Manual Air conditioning
  • Electrically operated tinted cab windows
  • Auto lights & wipers
  • Swivel Captains chairs
  • 7" touch screen & reversing camera
  • Front & Rear mud guards
  • Black Headlamp bezel in black
  • Black gloss front grill
  • Cab Kit with silver techno trim, leather steering wheel and leather gear lever
  • Headlight Eyebrows (Part of concept vehicle)
  • Side window wind deflectors (Part of concept vehicle)
  • 15mm wheel arch extensions (Part of concept vehicle)
  • CompleteHeat Whale 4.7 kW Dual-fuel space-saving heating - fast, powerful and efficient, runs on gas and/or electric with quiet night-time setting - and ducted heating throughout including bathrooms
  • Whale Heat Control panel with…
    • Modern display with capacitive touch operation
    • Precise temperature control for user comfort
    • Standby indication – Gas & Electric (Blue Standby – Orange on)
    • Water Temperature Selection (Frost, Eco & High)
    • Water temperature heat up status
    • Auto dim function
    • AC current limit selection
    • Proximity sensor (lights up before customer touches panel)
    • Single button reset at panel
  • Fully adjustable and co-ordinated swivel Captains’ seats with armrests
  • Half-height wardrobe with soft-close hinges
  • Easy bed make up, with pull-together sliding system
  • Double-glazed opening windows with night ventilation position (excluding cab windows)
  • Pleated blinds and flyscreens (excluding cab windows)
  • Thetford Triplex oven, grill and 3-burner gas hob (with auto-shut-off safety function) and glass lid creating additional work surface
  • 87L Fridge-freezer*
  • Matte black sink with integrated chopping board cover
  • Matte black fittings and taps
  • Well lit kitchen work area, with LED downlights
  • Worktop extension


  • TV point with dedicated location for comfortable viewing (230V, 12V and aerial connection)
  • Teleco Wing Omni-Directional Aerial
  • Stowaway dining table with dedicated storage
  • Electric entrance step
  • 25L LPG Underslung tank as standard, with LED level indicator
  • Improved-comfort height-adjustable Driver and Passenger seatbelts
  • Fully protected mains electric system with up to four 240V sockets
  • Contemporary switches, sockets and surrounds
  • Option for rear-mounted 2-cycle rack
  • Conveniently placed 12V control panel, incorporating water pump, lighting circuits, fresh water tank level and waste warning light when full
  • Sliding entrance door with window, and flyscreen and rain deflector
  • Rear double-barn door, with central locking - opening up the sleeping area to the outdoors
  • 20 Amp switchmode charger / transformer
  • 25m mains hook-up cable
  • Exterior mains electric inlet
  • Seat bases with space underneath for ample storage of larger, bulky items (battery stored here)
  • Smoke alarm
  • Carbon Monoxide (CO) alarm
  • Isolation taps for gas appliances
  • ‘Easy-slide’ - chariot-style socket
  • ISOFIX seat frame for CV80
  • Stylish graphics
  • ‘Tibero’ & ‘Grey’ craftsman-built cabinetry, handcrafted dove-tailed drawers, overhead lockers with positive locking, contrasting ‘Assoluto Quadro’ flush-fit kitchen units
  • Contemporary interior design and luxurious upholstery in ActivCare® with Hi-Performance, lightweight construction.
  • Durable ‘Porcelain White’ worktops throughout, including bathroom unit tops
  • Rain deflector with integrated LED Awning light
  • LED interior spotlights with concealed lights above overhead lockers (saving up to 80% battery consumption)
  • ‘Concrete Tile’ easy clean heavy-duty vinyl flooring
  • 400 X 400 MPK Rooflight
  • 90L underslung fresh water tank with manual water fill system
  • 45L Underslung waste water tank
  • Whale Expanse dual-fuel underslung 8L water heater
  • ‘Boutique’ washbowl basin with click-clack plug
  • 'Wall-mounted, retractable combined tap and shower head
  • Thetford toilet with auto-fill flush from on-board water tank
  • Domestic style bathroom door with high quality privacy lock
  • Automatic 140BHP Engine Upgrade** - £2,895
  • Automatic 180BHP Engine Upgrade** - £5,026
  • 10" Touchscreen with DAB & SATNAV** - £1,553
  • 10" Reversing camera with touchscreen, Satnav and DAB** - £2,090
  • Solar Panel - £622
  • Back Rack - £2,190
  • 2 Bike Rack - £495
  • Roll Out Awning - £925
  • Tow Bar (not compatible with back rack option)- £608
  • Winter Pack - £382
  • Mobile Internet & WiFi System - £382
  • Microwave Oven** - £255
  • Alarm System - £389
  • Tracker - £332
  • Cab Blinds - £516
  • 230V External Socket - £66

**Must be ordered prior to manufacture at factory

Erwin Hymer Group UK Ltd reserves the right to, and does alter from time to time, technical specifications, prices and model ranges as materials, model improvements and conditions require, and can accept no responsibility for discrepancies between these and subsequent models shown. The images and information on this page are for guidance purposes only. Please be sure to check our full current and technical specifications with your retailer before placing your order. Props shown are for photographic purposes only and are not included in the specification. Bed covers and additional scatter cushions shown are for demonstration purposes only, similar co-originating sets are available to purchase from Erwin Hymer Group Ltd retailer.
